定制 CUSTOMIZATIO
1:轴长 Shaft Lenght
2:轴形状 Shaft Shape
3:技术数据 Technical Date
| 额定电压 Rated voltage | 电机型号 Motor model | 减速比 Reduction ratio | 12.5 | 31.3 | 78.1 | 152 | 195 | 366 | 488 | |||||
| 箱体长L(mm) Gear box lenght | 16 | 16 | 17.5 | 19 | 19 | 20.5 | 20.5 | |||||||
| 12 | FF-130PA-09400 | 额定力矩(kgf.cm) Rated torque | 0.15 | 0.3 | 0.5 | 1.2 | 1.2 | 2.0 | 3.0 | |||||
| 额定转速(r/min) Rated speed | 486 | 200 | 85.5 | 41.1 | 32.2 | 18.1 | 13.2 | |||||||
| 堵转力矩（kgf.cm) Stall torque | 0.7 | 1.5 | 3.4 | 5.9 | 7.6 | 12.8 | 17.0 | |||||||
| 6 | FK-130PA-17160 | 额定力矩(kgf.cm) Rated torque | 0.15 | 0.4 | 0.8 | 1.5 | 1.5 | 3.0 | 3.5 | |||||
| 额定转速(r/min) Rated speed | 620 | 240 | 98.3 | 49.8 | 40.7 | 21.0 | 16.2 | |||||||
| 堵转力矩（kgf.cm) Stall torque | 1.0 | 2.1 | 4.8 | 8.4 | 10.8 | 18.2 | 24.3 | |||||||
| 电机型号 Motor model | 额定电压 Rated voltage | 空载/No Load | 负载/On Load | 备注 | |||||||||||||
| 电流 | 转速 | 扭矩 | 电流 | 转速 | |||||||||||||
| Current | Speed | Torque | Current | Speed | |||||||||||||
| V | mA | r/min | gf.cm | mA | r/min | ||||||||||||
| FF-130PA-09400 | 12 | 30 | 8000 | 10 | 100 | 6900 | |||||||||||
| FK-130PA-17160 | 6 | 100 | 9400 | 10 | 280 | 8500 | |||||||||||
