定制 CUSTOMIZATIO
1:轴长 Shaft Lenght
2:轴形状 Shaft Shape
3:技术数据 Technical Date
| 额定电压 Rated voltage | 电机型号 Motor model | 减速比 Reduction ratio | 119 | 207 | 321 | 534 | |||||||||
| 12 | RF-370CA-14370 | 额定力矩(kgf.cm) Rated torque | 1.5 | 3 | 4 | 7 | |||||||||
| 额定转速(r/min) Rated speed | 38.1 | 21.0 | 13.9 | 8.3 | |||||||||||
| 堵转力矩（kgf.cm) Stall torque | 11.8 | 18.5 | 28.6 | 47.6 | |||||||||||
| 6 | RK-370CA-25125 | 额定力矩(kgf.cm) Rated torque | 2.0 | 3.0 | 6.0 | 8.0 | |||||||||
| 额定转速(r/min) Rated speed | 55.8 | 32.3 | 19.9 | 12.5 | |||||||||||
| 堵转力矩（kgf.cm) Stall torque | 15.2 | 23.8 | 36.9 | 61.5 | |||||||||||
| 电机型号 Motor model | 额定电压 Rated voltage | 空载/No Load | 负载/On Load | 备注 | |||||||||||||
| 电流 | 转速 | 扭矩 | 电流 | 转速 | |||||||||||||
| Current | Speed | Torque | Current | Speed | |||||||||||||
| V | mA | r/min | gf.cm | mA | r/min | ||||||||||||
| RF-370CA-14370 | 12 | 17 | 5300 | 20 | 100 | 4600 | |||||||||||
| RK-370CA-25125 | 6 | 70 | 7800 | 10 | 200 | 7400 | |||||||||||
