定制 CUSTOMIZATIO
1:轴长 Shaft Lenght
2:轴形状 Shaft Shape
3:技术数据 Technical Date
| 额定电压 Rated voltage | 电机型号 Motor model | 减速比 Reduction ratio | 10 | 30 | 50.6 | 90 | 152 | 270 | 471 | 628 | 810 | |||||
| 箱体长L(mm) Gear box lenght | 17.8 | 21.5 | 24 | 24 | 26.5 | 26.5 | 29 | 29 | 29 | |||||||
| 6 | RF-520TB-22200 | 额定力矩(kgf.cm) Rated torque | 0.2 | 0.5 | 1.0 | 1.5 | 2.0 | 4.0 | 5.0 | 6.0 | 8.0 | |||||
| 额定转速(r/min) Rated speed | 472 | 160 | 89.0 | 52.1 | 31.6 | 17.4 | 10.4 | 7.9 | 6.1 | |||||||
| 堵转力矩（kgf.cm) Stall torque | 1.2 | 3.2 | 4.8 | 8.6 | 13.0 | 23.1 | 36.3 | 48.4 | 62.4 | |||||||
| 12 | RK-520TB-14510 | 额定力矩(kgf.cm) Rated torque | 0.2 | 0.5 | 1.2 | 1.5 | 3.0 | 5.0 | 6.0 | 7.0 | 10.0 | |||||
| 额定转速(r/min) Rated speed | 373 | 126 | 67.5 | 41.2 | 28.4 | 13.1 | 8.0 | 6.1 | 4.7 | |||||||
| 堵转力矩（kgf.cm) Stall torque | 1.3 | 3.5 | 5.3 | 9.4 | 14.4 | 25.5 | 40.0 | 53.4 | 68.9 | |||||||
| 电机型号 Motor model | 额定电压 Rated voltage | 空载/No Load | 负载/On Load | 备注 | |||||||||||||
| 电流 | 转速 | 扭矩 | 电流 | 转速 | |||||||||||||
| Current | Speed | Torque | Current | Speed | |||||||||||||
| V | mA | r/min | gf.cm | mA | r/min | ||||||||||||
| RF-520TB-22200 | 6 | 60 | 5800 | 20 | 260 | 5000 | |||||||||||
| RK-520TB-14510 | 12 | 20 | 4500 | 20 | 100 | 4000 | |||||||||||
