定制 CUSTOMIZATIO
1:轴长 Shaft Lenght
2:轴形状 Shaft Shape
3:技术数据 Technical Date
| 额定电压 Rated voltage | 电机型号 Motor model | 减速比 Reduction ratio | 10 | 30 | 50.6 | 90 | 114 | 146 | 270 | 471 | 备注 | ||||||
| 箱体长L(mm) Gear box lenght | 17.8 | 21.5 | 24 | 24 | 26.5 | 26.5 | 26.5 | 29 | 减速比114/146为优化型 | ||||||||
| 24 | RK-36ZY-10500 | 额定力矩(kgf.cm) Rated torque | 0.3 | 1.0 | 1.5 | 2.0 | 2.0 | 3.0 | 5.0 | 7.0 | |||||||
| 额定转速(r/min) Rated speed | 538 | 170 | 102 | 60.8 | 45.2 | 37.3 | 20.5 | 12.0 | |||||||||
| 堵转力矩（kgf.cm) Stall torque | 1.8 | 4.8 | 7.3 | 13.0 | 14.8 | 19.0 | 35.1 | 55.1 | |||||||||
| 24 | RK-36ZY-12335 | 额定力矩(kgf.cm) Rated torque | 0.5 | 1.5 | 2.0 | 3.0 | 3.0 | 4.0 | 6.0 | 8.0 | |||||||
| 额定转速(r/min) Rated speed | 802 | 260 | 159 | 92.6 | 74.7 | 57.9 | 32.3 | 18.8 | |||||||||
| 堵转力矩（kgf.cm) Stall torque | 2.7 | 7.4 | 11.3 | 20.0 | 22.8 | 29.2 | 54.0 | 84.9 | |||||||||
| 电机型号 Motor model | 额定电压 Rated voltage | 空载/No Load | 负载/On Load | 备注 | |||||||||||||
| 电流 | 转速 | 扭矩 | 电流 | 转速 | |||||||||||||
| Current | Speed | Torque | Current | Speed | |||||||||||||
| V | mA | r/min | gf.cm | mA | r/min | ||||||||||||
| RK-36ZY-10500 | 24 | 45 | 6600 | 50 | 200 | 5100 | |||||||||||
| RK-36ZY-12335 | 24 | 53 | 10000 | 50 | 272 | 8500 | |||||||||||
