定制 CUSTOMIZATIO
1:轴长 Shaft Lenght
2:轴形状 Shaft Shape
3:技术数据 Technical Date
| 额定电压 Rated voltage | 电机型号 Motor model | 减速比 Reduction ratio | 1980 | ||||||
| 3 | RF-330CA-11360 | 额定力矩(kgf.cm) Rated torque | 2.5 | ||||||
| 额定转速(r/min) Rated speed | 1.32 | ||||||||
| 堵转力矩（kgf.cm) Stall torque | 16.5 | ||||||||
| 电机型号 Motor model | 额定电压 Rated voltage | 空载/No Load | 负载/On Load | 备注 | |||||||||||||
| 电流 | 转速 | 扭矩 | 电流 | 转速 | |||||||||||||
| Current | Speed | Torque | Current | Speed | |||||||||||||
| V | mA | r/min | gf.cm | mA | r/min | ||||||||||||
| RF-330CA-11360 | 3 | 22 | 3100 | 5 | 90 | 2400 | |||||||||||
