定制 CUSTOMIZATIO
1:轴长 Shaft Lenght
2:轴形状 Shaft Shape
3:技术数据 Technical Date
| 额定电压 Rated voltage | 电机型号 Motor model | 减速比 Reduction ratio | 177 | |||||||
| 2.2V-3.0V | RF-300CA-09400 | 顶杆移动距离 (mm) Push Rod Movement Distance | 4.5Max | |||||||
| 限流(mA) Current Limiting | 120 | |||||||||
| 堵转力（kgf) Min Thrust | 7.0 | |||||||||
| 电机型号 Motor model | 额定电压 Rated voltage | 空载/No Load | 负载/On Load | 备注 | |||||||||||||
| 电流 | 转速 | 扭矩 | 电流 | 转速 | |||||||||||||
| Current | Speed | Torque | Current | Speed | |||||||||||||
| V | mA | r/min | gf.cm | mA | r/min | ||||||||||||
| RF-300CA-09400 | 3 | 38 | 3400 | 4 | 90 | 2300 | |||||||||||
