定制 CUSTOMIZATIO
1:轴长 Shaft Lenght
2:轴形状 Shaft Shape
3:技术数据 Technical Date
| 额定电压 Rated voltage | 电机型号 Motor model | 减速比 Reduction ratio | 16 | 20 | 25 | 64 | 100 | 125 | 256 | 备注 | ||||||
| 箱体长L(mm) Gear box lenght | 28.9 | 28.9 | 28.9 | 34.6 | 34.6 | 34.6 | 40.3 | 双通道编码器分辨率:2PPR | ||||||||
| 4.5 | RS-390SH-3856 | 额定力矩(kgf.cm) Rated torque | 1.5 | 1.5 | 2.0 | 4.0 | 6.0 | 8.0 | 10 | |||||||
| 额定转速(r/min) Rated speed | 300 | 254 | 200 | 80.0 | 51.6 | 40.7 | 21.7 | |||||||||
| 堵转力矩（kgf.cm) Stall torque | 6.3 | 7.9 | 9.9 | 21.7 | 33.9 | 42.4 | 74.6 | |||||||||
| 12 | RS-390SH-3560R | 额定力矩(kgf.cm) Rated torque | 3.0 | 4.0 | 5.0 | 8.0 | 10 | 10 | - | |||||||
| 额定转速(r/min) Rated speed | 655 | 516 | 413 | 173 | 115 | 94.2 | - | |||||||||
| 堵转力矩（kgf.cm) Stall torque | 15.4 | 19.2 | 24.0 | 52.9 | 82.7 | 103 | - | |||||||||
| 电机型号 Motor model | 额定电压 Rated voltage | 空载/No Load | 负载/On Load | 备注 | |||||||||||||
| 电流 | 转速 | 扭矩 | 电流 | 转速 | |||||||||||||
| Current | Speed | Torque | Current | Speed | |||||||||||||
| V | mA | r/min | gf.cm | mA | r/min | ||||||||||||
| RS-390SH-3856 | 4.5 | 280 | 6400 | 100 | 1700 | 5200 | |||||||||||
| RS-390SH-3560R | 12 | 290 | 13300 | 150 | 2000 | 11800 | |||||||||||
